DS-2CE56C2P-IT3
|
Hikvision recently announced the release of it’s EXIR infrared technology for Hikvision network security cameras. Compared to conventional IR network security cameras, Hikvision’s high-performance EXIR series delivers the most advanced levels of night-time surveillance available on the market today – with best-in-breed illuminators for any dark environment, indoors or out. Hikvision recently announced the release of it’s EXIR infrared technology for Hikvision network security cameras. Compared to conventional IR network security cameras, Hikvision’s high-performance EXIR series delivers the most advanced levels of night-time surveillance available on the market today – with best-in-breed illuminators for any dark environment, indoors or out. |
|
| General | ||
|---|---|---|
| Operating Conditions: | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 V DC±10% | |
| Power Consumption: | Max. 5 W | |
| Weather Proof: | IP66 | |
| IR Range: | Approx 30 to 40 meters | |
| Dimension: | Φ114.6× 89.1mm(Φ4.5” × 3.5”) | |
| Weight: | 300 g (0.66 lbs) | |
| Camera | ||
|---|---|---|
| Image Sensor: | 1/3'' PICADIS | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1280 (H) × 960 (V) | |
| Min. Illumination: | 0.1Lux @ (F1.2,AGC ON),0 Lux with IR 0.3Lux @ (F2.3,AGC ON),0 Lux with IR |
|
| Shutter Time: | 1/25(1/30) s to 1/25,000(1/30,000) s | |
| Lens: | 12mm @ F1.8(2.8mm,3.6mm, 6mm, 8mm, 16mm optional), Angle of view: 22.72° (12mm) |
|
| Lens Mount: | M12 | |
| Adjustment Range: | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Horizontal Resolution: | 720TVL | |
| Synchronization: | Internal Synchronization | |
| Video Output: | 1Vp-p Composite Output (75Ω/BNC) | |
| S/N Ratio: | More than 62 dB | |
| BLC: | On | |
